Resins / 460nm Resins
Rigid UVFR 3D Resin
Available on back-order
MAGDBPBBKV205
Flame-retardant engineering resin for electrical components and high-performance industrial applications.
Colour: Black
Size Bottle: 5Kg
£295.00 excl VAT
Select Quantity
5
FREE UK shipping on orders over £250
Volume Resin Discounts
| Units | Order Quantity | % Discount | Price per kg |
|---|---|---|---|
| 1-3 | 5-15kg | - | £59 |
| 4-11 | 20-55kg | 10% | £53.10 |
| 12-19 | 60-95kg | 15% | £50.15 |
| 20+ | 100kg+ | 25% | £44.25 |
Resins / 460nm Resins
Rigid UVFR 3D Resin
Available on back-order
MAGDBPBBKV205
Flame-retardant engineering resin for electrical components and high-performance industrial applications.
Colour: Black
Size Bottle: 5Kg
£295.00 excl VAT
Select Quantity
5
FREE UK shipping on orders over £250
Volume Resin Discounts
| Units | Order Quantity | % Discount | Price per kg |
|---|---|---|---|
| 1-3 | 5-15kg | - | £59 |
| 4-11 | 20-55kg | 10% | £53.10 |
| 12-19 | 60-95kg | 15% | £50.15 |
| 20+ | 100kg+ | 25% | £44.25 |
UL 94 V-0 Flame-Retardant Engineering Resin for Demanding Applications
Rigid UVFR is a flame-retardant engineering resin developed for applications requiring exceptional heat resistance, rigidity and dimensional accuracy. Certified to UL 94 V-0 at 2mm and V-1 at 1.5mm, it combines reliable flame-retardant performance with excellent printability. Designed and manufactured in the UK, Rigid UVFR is halogen free, TPO free and easy to process.
High Heat Resistance
With a heat deflection temperature exceeding 250°C, Rigid UVFR is suitable for demanding high-temperature environments and applications.
Rigid
Produces rigid, dimensionally accurate parts with excellent mechanical properties, supporting applications where stability and precision are critical.
Halogen Free
Halogen-free formulation supports applications requiring reduced smoke toxicity and improved fire safety performance without compromising print quality.
TPO Free
Formulated without TPO photo initiators, supporting regulatory compliance requirements while maintaining reliable curing and consistent print performance.
UL 94 V-0 Flame-Retardant Engineering Resin for Demanding Applications
Rigid UVFR is a flame-retardant engineering resin developed for applications requiring exceptional heat resistance, rigidity and dimensional accuracy. Certified to UL 94 V-0 at 2mm and V-1 at 1.5mm, it combines reliable flame-retardant performance with excellent printability. Designed and manufactured in the UK, Rigid UVFR is halogen free, TPO free and easy to process.
High Heat Resistance
With a heat deflection temperature exceeding 250°C, Rigid UVFR is suitable for demanding high-temperature environments and applications.
Rigid
Produces rigid, dimensionally accurate parts with excellent mechanical properties, supporting applications where stability and precision are critical.
Halogen Free
Halogen-free formulation supports applications requiring reduced smoke toxicity and improved fire safety performance without compromising print quality.
TPO Free
Formulated without TPO photo initiators, supporting regulatory compliance requirements while maintaining reliable curing and consistent print performance.
Properties
| Post-cured* | ||
| Tensile Properties | ||
| Tensile Modulus | 4170 MPa | |
| Elongation at Break | 2.3% | |
| Flexural Properties | ||
| Flexural Strength | 115 MPa | |
| Flexural Modulus | 3400 MPa | |
| Impact Properties | ||
| Impact Strength Notched Izod | 22 J/m | |
| Post-cured* | Post-cured + Anneal** | |
| Thermal Properties | ||
| Heat Deflection Temperature (@0.45 MPa) | 260°C | - |
| Heat Deflection Temperature (@1.82 MPa) | 94°C | >120°C |
| Post-cured* | Standard | |
| Fire Properties | ||
| Flammability |
V-0 (3.0 mm) V-0 (2.5 mm) V-0 (2.0 mm) V-1 (1.5 mm) |
UL 94 |
|
*Post-cured for 2 hrs at 60°C in Photocentric Cure L2. **Some mechanical and thermal properties can be improved by thermal annealing. Post-cured for 2 hrs at 60°C in Photocentric Cure L2, thermally annealed for 3h at 150°C. |
||
Made in the UK
Properties
| Post-cured* | ||
| Tensile Properties | ||
| Tensile Modulus | 4170 MPa | |
| Elongation at Break | 2.3% | |
| Flexural Properties | ||
| Flexural Strength | 115 MPa | |
| Flexural Modulus | 3400 MPa | |
| Impact Properties | ||
| Impact Strength Notched Izod | 22 J/m | |
| Post-cured* | Post-cured + Anneal** | |
| Thermal Properties | ||
| Heat Deflection Temperature (@0.45 MPa) | 260°C | - |
| Heat Deflection Temperature (@1.82 MPa) | 94°C | >120°C |
| Post-cured* | Standard | |
| Fire Properties | ||
| Flammability |
V-0 (3.0 mm) V-0 (2.5 mm) V-0 (2.0 mm) V-1 (1.5 mm) |
UL 94 |
|
*Post-cured for 2 hrs at 60°C in Photocentric Cure L2. **Some mechanical and thermal properties can be improved by thermal annealing. Post-cured for 2 hrs at 60°C in Photocentric Cure L2, thermally annealed for 3h at 150°C. |
||
Made in the UK
Applications
Rigid UVFR is designed for applications requiring flame retardancy, exceptional heat resistance and dimensional accuracy. Combining UL 94 V-0 certification with a heat deflection temperature exceeding 250°C, it is well suited to electrical, electronic and industrial applications where safety and performance are critical.
Electrical and Electronic Enclosures
Produce electrical and electronic enclosures requiring flame-retardant performance, dimensional accuracy and long-term reliability in demanding operating environments.
Battery Housings
Manufacture battery housings requiring heat resistance, rigidity and flame-retardant properties for demanding energy storage and power applications.
Automotive, Aerospace and Railway Interiors
Suitable for interior components requiring flame-retardant performance, low smoke toxicity and compliance-focused material characteristics across regulated industries.
Connectors and Fittings
Create detailed connectors and fittings with excellent dimensional stability, supporting precise assembly and reliable performance in electrical systems.
Applications
Rigid UVFR is designed for applications requiring flame retardancy, exceptional heat resistance and dimensional accuracy. Combining UL 94 V-0 certification with a heat deflection temperature exceeding 250°C, it is well suited to electrical, electronic and industrial applications where safety and performance are critical.
Electrical and Electronic Enclosures
Produce electrical and electronic enclosures requiring flame-retardant performance, dimensional accuracy and long-term reliability in demanding operating environments.
Battery Housings
Manufacture battery housings requiring heat resistance, rigidity and flame-retardant properties for demanding energy storage and power applications.
Automotive, Aerospace and Railway Interiors
Suitable for interior components requiring flame-retardant performance, low smoke toxicity and compliance-focused material characteristics across regulated industries.
Connectors and Fittings
Create detailed connectors and fittings with excellent dimensional stability, supporting precise assembly and reliable performance in electrical systems.
Durable DL902 Plant Based
5
Durable DL902 Plant Based
5
Frequent Asked Quetions
What does UL 94 V-0 mean?
UL 94 V-0 is a flammability classification indicating that a material self-extinguishes within 10 seconds after ignition and does not produce burning drips. Rigid UVFR achieves UL 94 V-0 at 2mm thickness and UL 94 V-1 at 1.5mm, making it suitable for applications where flame retardancy and fire safety compliance are critical.
What is Rigid UVFR resin used for?
Rigid UVFR is used for electrical and electronic enclosures, connectors, battery housings and high-temperature industrial components. It is also suitable for automotive, aerospace and railway interior parts where flame retardancy, dimensional accuracy and high heat resistance are required.
Why are TPO-free and halogen-free resins important?
TPO-free and halogen-free formulations reduce hazardous substances associated with emissions and material decomposition during processing or fire exposure. This improves smoke toxicity performance and supports applications where regulatory compliance, workplace safety and material safety standards are important, particularly in electrical, transport and industrial environments.
Which 3D printers are compatible with Rigid UVFR?
Rigid UVFR is compatible with 385–405nm LCD and MSLA resin 3D printers. This includes most modern desktop and industrial resin printing systems operating within this wavelength range, allowing reliable performance across a wide range of professional 3D printing equipment.
Why choose Rigid UVFR over standard engineering resins?
Rigid UVFR offers significantly higher heat resistance, UL 94 V-0 flame-retardant performance and improved safety characteristics compared to standard engineering resins. With HDT exceeding 250°C, halogen-free composition and excellent dimensional stability, it is designed for applications where electrical safety, thermal performance and regulatory compliance are critical.
Frequent Asked Quetions
What does UL 94 V-0 mean?
UL 94 V-0 is a flammability classification indicating that a material self-extinguishes within 10 seconds after ignition and does not produce burning drips. Rigid UVFR achieves UL 94 V-0 at 2mm thickness and UL 94 V-1 at 1.5mm, making it suitable for applications where flame retardancy and fire safety compliance are critical.
What is Rigid UVFR resin used for?
Rigid UVFR is used for electrical and electronic enclosures, connectors, battery housings and high-temperature industrial components. It is also suitable for automotive, aerospace and railway interior parts where flame retardancy, dimensional accuracy and high heat resistance are required.
Why are TPO-free and halogen-free resins important?
TPO-free and halogen-free formulations reduce hazardous substances associated with emissions and material decomposition during processing or fire exposure. This improves smoke toxicity performance and supports applications where regulatory compliance, workplace safety and material safety standards are important, particularly in electrical, transport and industrial environments.
Which 3D printers are compatible with Rigid UVFR?
Rigid UVFR is compatible with 385–405nm LCD and MSLA resin 3D printers. This includes most modern desktop and industrial resin printing systems operating within this wavelength range, allowing reliable performance across a wide range of professional 3D printing equipment.
Why choose Rigid UVFR over standard engineering resins?
Rigid UVFR offers significantly higher heat resistance, UL 94 V-0 flame-retardant performance and improved safety characteristics compared to standard engineering resins. With HDT exceeding 250°C, halogen-free composition and excellent dimensional stability, it is designed for applications where electrical safety, thermal performance and regulatory compliance are critical.
